Air to Water Heat Pump Hot Water System All in One Heat Pump Water Heater

Short Description:

FAST-HEATING ALL IN ONE heat pump water heater

Meigaomei all in one heat pump water heater is equipped with high standard and high quality components, which assures high COP output and long-term service life, it is special designed for domesitc heat pump water heater, heating capacity range is from180L-250L, with 1.5HP compressor, no need any electric heater.

Note: For detailed product specifications and quotations, please contact us.

Send email to us

Product Detail

Product Tags

Features:

*Economical and high-efficiency: Save about 70% heating cost than electric heaters.
*Simple and fast installation: 3 steps installation (connect cold water inlet and hot water oulet pipe, power supply calble), no need drilling holes on wall.
*Quiet Running: High-efficiency, low noise rotary compressor, low noise fan, the main unit works at extremely quiet condition.
*Intelligent: Full automatic and intelligent controller with wifi mobile phone cotrol, no need any manual operation.

KA-PC(internal coil condenser)all-in-one heat pump water heater
Model	KA-PC-100	KA-PC-150	KA-PC-180	KA-PC-250	KA-PC-300
Tank capacity	100 liters	150 liters	180 liters	250 liters	300 liters
Ext.dimension(mm)	φ560×1140	φ560×1430	φ560×1650	φ640*1620	φ640*1805
Inner tank material	SUS304 stainless steel
Outer material	white /silver /golden color painted steel
Insulation material	High density polyurethane foam(Non-CFC)/50MM
Condenser	Micro-channel /high efficiency tank-external condenser
Evaporator	Aluminum fins +copper flow tubes
Rated/Max water temp	55℃/60℃
Power supply	AC220V~240V/50Hz(60Hz model can be produced customized)
Input Power(KW)	0.55	0.85	0.85	1.15	1.15
Nominal heat capacity (KW)*	2.2	3.4	3.4	4.6	4.6
Working current(A)	1.6~3.1	2.3~4.8	2.3~4.8	3.8~6.5	3.8~6.5
Max input power(KW)	0.69	1.06	1.06	1.44	1.44
Refrigerant	R410a/R32/R417 /R134A
Noise	<55db

KA-MC(Micro channel condenser)all-in-one heat pump water heater
Model	KA-MC-100	KA-MC-150	KA-MC-180	KA-MC-250	KA-MC-300
Tank capacity	100 liters	150 liters	180 liters	250 liters	300 liters
Ext.dimension(mm)	φ560×1140	φ560×1430	φ560×1650	φ640*1620	φ640*1805
Inner tank material	SUS304 stainless steel
Outer material	white /silver /golden color painted steel
Insulation material	High density polyurethane foam(Non-CFC)/50MM
Condenser	Micro-channel condenser wraped outside tank body
Evaporator	Aluminum fins +copper flow tubes
Rated/Max water temp.	55℃/60℃
Power supply	AC220V~240V/50Hz
Input Power(KW)	0.55	0.85	0.85	1.15	1.15
Nominal heat capacity (KW)*	2.2	3.4	3.4	4.6	4.6
Working current(A)	1.6~3.1	2.5~4.8	2.5~4.8	3.8~6.5	3.8~6.5
Max input power(KW)	0.69	1.06	1.06	1.44	1.44
Refrigerant	R410a/R32/R417 /R134A
Noise	<55db
