MONOBLOCK HEAT PUMP Heating / Cooling / DHW / DC Inverter / Residential Type

Short Description:

Features

R290 refrigerant,low GWP(GWP=3)

Energy class:A+++

Stable operation at -25°C

Outlet water temperature up to 75℃

Power Detection Function

SG-READY Function

5-Inch TFT True Color Screen

5G/2 .4G Compatible WIFI Module

Dual Temperature Zone

Reserved RS485 Communication Port

Linkage Control with PV Function

Note: For detailed product specifications and quotations, please contact us.

Send email to us

Product Detail

Product Tags

TECHNICAL DATA
Model			BLN-006TC1	BLN-008TC1	BLN-008TC3	BLN-012TC1	BLN-012TC3	BLN-018TC1	BLN-018TC3
Power supply		V/Ph/Hz	220~240//50	220~240/1/50	380~415/3/50	220~240/1/50	380~415/3/50	220~240/1/50	380~415/3/50
Nominal Heating (Max) (A7/6℃,W30/35℃)	Heating capacity	kW	2.92～9.10	4.10-12.10	4.10-12.10	4.30～15.20	4.30～15.20	7.24～21.90	7.24～21.90
	Power input	kW	0.61～2.11	0.79-2.85	0.79-2.85	0.87～3.73	0.87～3.73	1.50～5.88	1.50～5.88
	Current input	A	2.80～9.25	3.45-13.04	1.62-4.57	4.02～16.38	1.78～6.04	6.86～30.25	2.82～9.16
	COP	W/W	4.31～5.66	4.24-5.57	4.24-5.57	4.07～5.57	4.07～5.57	3.82～5.59	3.82～5.59
	Heating capacity	kW	2.99~8.16	4.05-12.15	4.05-12.15	4.25～14.55	4.25～14.55	6.36～19.45	6.36～19.45
Nominal Heating (Max) (A7/6℃,W47/55℃	Power input	kW	1.03~2.92	1.38-4.06	1.38-4.06	1.45～4.28	1.45～4.28	2.15～6.85	2.15～6.85
	Current input	A	4.57~12.79	5.73-17.70	2.70-6.43	6.71～18.80	2.84～6.78	9.84～30.12	3.71～10.60
	COP	W/W	2.79～3.46	2.99-3.45	2.99-3.45	2.83～3.45	2.83～3.45	2.84～3.57	2.84～3.57
Nominal Cooling(Max) (A35/24℃,W12/7℃)	Cooling capacity	kW	1.38~5.70	3.65-8.59	3.65-8.59	3.65～11.04	3.65～11.04	4.55～17.20	4.55～17.20
	Power input	kW	0.67~2.44	1.12-3.31	1.12-3.31	1.12~3.97	1.12～3.97	1.85～7.31	1.85～7.31
	Current input	A	3.06~10.27	5.18-14.47	1.97-5.25	5.18~17.44	1.97～6.30	8.47～32.1	2.99～11.26
ERP level(outlet water temp.at 35℃)		/	A+++	A+++	A+++	A+++	A+++	A+++	A+++
Max.input power		kW	3.5	5.40	5.85	5.40	5.85	7.5	10.5
Max.input current		A	15.0	25.0	10.0	25.0	10.0	35.0	17.0
Refrigerant Type/Charge/GWP		…/kg	R290/0.55/3	R290/1.05/3	R290/1.05/3	R290/1.05/3	R290/1.05/3	R290/1.4/3	R290/1.4/3
Rated water fow		m³h	1.00	1.4	1.4	2.06	2.06	3.1	3.1
Fan quantity		/	1	1	1	1	1	2	2
Fan motor type		/	DC inverter
Compressor		/	DC inverter
Circulating pump		/	nverter type/Built-i
IP class		/	IPX4
Sound pressure at 1m distance		dB(A)	46	43	43	53	54	56	56
Max outlet water temperature		℃	75	75	75	75	75	75	75
Water piping connections		/	G1	G1	G1	G1	G1	G1-1/4	G1-1/4
Water Pressure drop		kPa	20	20	20	20	20	55	55
Operating temperature range (heating mode)		℃	-25~45
Operating temperature range (cooling mode)		℃	16~45
Unpacked dimensions (LDH)		mm	1187418805	1287448904	1287448904	1287448904	1287448904	11874881456	11874881456
Packed dimensions(LDH)		mm	1217463920	13174931020	13174931020	13174931020	13174931020	12175381570	12175381570
UnPacked weight		kg	110	134	134	134	134	195	195
Packed weight		kg	122	146	146	146	146	208	208
